4 | Oolio Order Manager Integration - Transaction Queue Device Setup Guide

This article covers the Transaction Queue Device setup for the Oolio Order Manager Integration with Bepoz.

Minimum Bepoz version of v4.7.3.2 and onwards
For an Operator to be able to setup Oolio Order Manager Integration, the following Operator privileges must be enabled:

In order for Bepoz to be able to send the order status updates from Bepoz to Oolio Order Manager, a Transaction Queue Device has to be created
N.B. When setting up in a Multi Venue environment, ensure the Transaction Queue device is configured to run on the remote venue server
After logging into BackOffice, complete the following steps to create & configure a Oolio Order Manager Transaction Queue Device:

Navigate to the System Setup component in the sidebar, expand, and select Venue, Stores & Tills to open the Venue & Till List Tab
Highlight the desired Till and click on the Add New Device button in the header; when prompted select 'Blank Device' and a New Device and Interfaces Maintenance window will open
Enter a relevant Device Name, set the Device Type to 'Transaction Queue', set the External DLL Name to 'Transqoolioordermanager.Dll', and the Class Name to 'Oolio Order Manager Device'
Click the "Settings" button at the bottom of the window to open a separate "Oolio Order Manager Settings" window

Type Mapping:

Map the TableGroup to each Order Type
Select the Order Type and Table Group respectively from the drop down and click on ‘Add’ button to add the selection

Note: The TableGroup for Oolio Order Manager Delivery and Pickup order types must be created within the Venue Maintenance "Tables" Tab

2. Click ‘OK’ to save the settings and this will exit from the Oolio Order Manager Settings window

3. Click 'OK' again on the Device and Interface Maintenance window to save the Oolio Order Manager Transaction Queue Device settings
