1 | Quest Integration Setup

This article covers the installation and setup for Quest Payment System which is an integrated system for EFTPOS, Mobile POS Solutions and Mobile EFTPOS Products.

This article covers the installation and setup for Quest Payment System which is an integrated system for EFTPOS, Mobile POS Solutions and Mobile EFTPOS Products.

• Prior to installing EftposPlus the following should be considered

Use Administrator Rights

• For EftposPlus to be successfully installed, the user profile for signing on to Windows must have local administrator rights
• Without local administrative privileges the user will not have the necessary permissions to install EftposPlus and modify settings on the computer
• For detailed instructions on configuring Windows User Accounts and Permissions please refer to the documentation provided with the relevant operating system
• When you have completed the installation and configuration of EftposPlus you may want to restrict the access your users have to the computer by removing them from the Administrator group

Network Configuration

• TCP/IP is used by EftposPlus to communicate over the local and wide area networks and between each EftposPlus application
• TCP/IP is required on all EFTPOS Nodes, including single terminal Nodes

Single Terminal Node

• For a single terminal Node the options to configure TCP/IP are:
• To install a Network card and configure TCP/IP
• If using Windows NT, install the NT supplied ‘MS Loopback Adapter’
• If using Windows 98, install a standard 28800 modem and configure TCP/IP

Windows Services

• When EftposPlus is initially installed, EftposPlus needs to be launched by double clicking the Start EftposPlus Enterprise desktop icon
• By default EftposPlus does not run as a service
• However, the EftposPlus applications can be run as services primarily to ensure that the EFTPOS Gateway is available to the Site for processing EFT transactions and the Terminal Nodes can be accessed from an Administration Node, even if they are not logged onto to Windows
• Prior to registering the applications as services, you should ensure the installation and configuration of EftposPlus is complete and functions correctly

Registering EftposPlus as Service

• To register the EftposPlus applications as services:
1. Start EftposPlus by double clicking the Start EftposPlus Enterprise shortcut on the desktop
2. From the EftposPlus Administrator, select Tools| EftposPlus Settings
3. Enter the Help Desk Password then click OK
4. Select the Advanced tab, from EftposPlus Settings
5. From the <Show:> drop down list, select System Settings
6. From the Property list, select Run EftposPlus as Services, then click Edit…
7. Select Yes to activate EftposPlus as services, then select OK
8. Click Close to save the changes you have made to EftposPlus Settings
9. A dialog is displayed, stating you must restart this computer for this change to take effect. Click OK
10. To restart the computer, firstly close EftposPlus by double clicking the Stop EftposPlus Enterprise shortcut on the desktop
11. Place the EPPGO.BAT file as a shortcut in the Windows Startup Folder. This file is located in the directory:\\Program Files\Quest Software\EftposPlus\AppsFolder
12. Select Start | Shutdown… from Windows
13. When the computer restarts, the EftposPlus applications will now be running as services
